CNC E5 Atc Nesting CNC Router for Cabinets Doors Furniture
  • CNC E5 Atc Nesting CNC Router for Cabinets Doors FurnitureCNC E5 Atc Nesting CNC Router for Cabinets Doors Furniture
  • CNC E5 Atc Nesting CNC Router for Cabinets Doors FurnitureCNC E5 Atc Nesting CNC Router for Cabinets Doors Furniture
  • CNC E5 Atc Nesting CNC Router for Cabinets Doors FurnitureCNC E5 Atc Nesting CNC Router for Cabinets Doors Furniture
  • CNC E5 Atc Nesting CNC Router for Cabinets Doors FurnitureCNC E5 Atc Nesting CNC Router for Cabinets Doors Furniture

CNC E5 Atc Nesting CNC Router for Cabinets Doors Furniture

Excitech is a professional leader China CNC E5 Atc Nesting CNC Router for Cabinets Doors Furniture manufacturers with high quality and reasonable price. Welcome to contact us. The heavy duty machine with 8-slot carousel tool magazine, suitable for gravity cutting, with wide function such as routing, drilling, cutting, side milling, edge chamfering, etc.

Model:E5

Send Inquiry

Product Description


Excitech is a professional leader China CNC E5 Atc Nesting CNC Router for Cabinets Doors Furniture manufacturers with high quality and reasonable price. Welcome to contact us.

The heavy duty machine with 8-slot carousel tool magazine, suitable for gravity cutting, with wide function such as routing, drilling, cutting, side milling, edge chamfering, etc. Boring aggregate can be optional. Vacuum table with great absorption strength - adsorb different areas of materials, also can use fixtures to hold various shaped materials with fixture, which is flexible and convenient. At the same time, the drilling bank is optional according to the customer's needs.

Series

E5-1224D E5-1530D E5-2030D E5-2040D

Travelling size

2500*1260*330mm 3100*1570*330mm 3350*2100*330mm 4350*2100*330mm

Working size

2480*1230*200mm 3080*1560*200mm 3050*2032*200mm 3940*2032*200mm

Table size

2500*1240mm 3100*1570mm 3100*2100mm 4020*2100mm

Transmission

X/ Y rack and pinion drive, Z ball screw drive

Table structure

  T-slot and vacuum table

Spindle power

  9.6/12kw

Spindle speed

  24000r/min

Travelling speed

80m/min

Working speed

 20m/min

Tool magazine

Carousel 8/12/16 slots

Driving system

Yaskawa

Voltage

AC380/ 3PH/ 50HZ

Controller

OSAI/Syntec

Drill Bank Configuration

5+4 vertical drilling

Optional

9 vertical + 6 horizontal drilling+1 saw





Service

■  From your first inquiries about our machine to close the deal to installation to technical support and maintenance, our team will be always with you.


■  Excitech provides 24hr factory support with a team of highly experienced engineers that serve customers and partners around the world , around the clock.

■  No matter whether the machine is used in North America or Africa, we can run diagnostics via dial-in on any of our computer-equipped machines for troubleshooting and correct controller settings to have you running again in a minute.


6.FAQ


1. How long is the machine warranty period? ?


Answer:EXCITECH offers 12 months warranty for service issue that are not caused by operator's errors. Service and support are available throughout the service life of a machine at fair and reasonable costs after warranty expires.


2. How is your after-sales service?


Answer:Excitech provides 24hr factory support with a team of highly experienced engineers that serve customers and partners around the wold , around the clock.


3. Where is your factory located?


Answer:Shandong and Guangdong. For more information, please refer to ABOUT US.



4. Are you a trading company or a manufacturer?


Answer: Excitech is a professional machinery manufacturing company. For more information, please refer to ABOUT US.
